AKD Benutzerhandbuch | 24.12.9 DOUT9.STATEU to DOUT11.STATEU

24.12.9 DOUT9.STATEU to DOUT11.STATEU

General Information
Type
Description
Units
Range
Default
Value
Data Type
Start Version M_01-05-00-000
Variants Supported
AKD Base
AKD with Position Indexer
AKD EtherCAT
AKD CANopen
AKD BASIC
AKD SynqNet
AKD EtherNet/IP
AKD Profinet
AKD sercos ® III
AKD-N
AKD-C
Fieldbus Information
DOUT9.STATEU
DOUT10.STATEU
DOUT11.STATEU
Fieldbus
Modbus
Description
This parameter allows the user to set the level of the output signal, when the IO is set to output mode.
Parameter value is 0 if signal is low and 1 if signal is high. DIOx.INV can affect the signals driven onto the
X9 connector.
This parameter can be written at any time. The value is only guaranteed to correspond to the output on the
X9 connector when DRV.EMUEMODE is set to 10 and the DIOX.DIR is 0.
Example
556 KOLLMORGEN | Mai 2014
NV Parameter
Allows user to set level of selected pin to high or
low.
N/A
0 to 1
0
U8
Variant
Parameter Fieldbus
Profinet
sercos ® III
Profinet
sercos ® III
Profinet
sercos ® III
Index/Subindex
1566 DOUT9.STATEU
1458 DOUT10.STATEU
1462 DOUT11.STATEU
Supported
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
No
No
Address Attributes Signed?
Byte
2783
2 Octets
Byte
2729 No
2 Octets
Byte
2731
2 Octets
Is 64 bit? Attributes Signed? Object Start Version
No 8 bit No M_01-06-03-000
