AKD Benutzerhandbuch | 24.5.1 AOUT2.CUTOFF
24.5.1 AOUT2.CUTOFF
General Information
Type
Description
Units
Range
Default
Value
Data Type
Start Version M_01-06-03-000
Variants Supported
Supported by any AKD with extended IO.
Fieldbus Information
Fieldbus Index/Subindex Is 64 bit? Attributes Signed? Object Start Version
Modbus 1272
Description
AOUT2.CUTOFF sets the cutoff frequency in Hz for a single-pole low-pass
filter on the Analog Output 2.
A value of 0 Hz will turn off the filter and will allow all frequencies to pass through.
The filter can be used with all modes of Analog Output 2.
Related Topics
Analogausgang (S. 129)
444
KOLLMORGEN | Mai 2014
NV Parameter
Sets the analog output 2 low-pass filter cutoff
frequency.
Hz
0 to 10,000 Hz
0 Hz
Float
Yes
32-bit
No
M_01-06-03-000
