AKD Benutzerhandbuch | 24.33.1 REC.ACTIVE

24.33.1 REC.ACTIVE

General Information
Type
Description
Units
Range
Default
Value
Data Type
See Also
Start Version M_01-00-00-000
Variants Supported
AKD Base
AKD with Position Indexer
AKD EtherCAT
AKD CANopen
AKD BASIC
AKD SynqNet
AKD EtherNet/IP
AKD Profinet
AKD sercos ® III
AKD-N
AKD-C
Fieldbus Information
Fieldbus
Profinet
sercos ® III
Description
REC.ACTIVE indicates whether or not data recording is in progress. Recording is in progress if the trigger
was met and the recorder is recording all data.
Related Topics
Oszilloskop (S. 250)
1030 KOLLMORGEN | Mai 2014
R/O Parameter
Indicates if data recording is in progress
(active).
N/A
0 to 1
N/A
Integer
REC.DONE (S. 1032), REC.OFF (S. 1035)
Variant Supported
Address Attributes Signed?
Byte
2354 No
2 Octets
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
