AKD Benutzerhandbuch | 24.3.2 AIN2.DEADBAND

24.3.2 AIN2.DEADBAND

General Information
Type
Description
Units
Range
Default
Value
Data Type
Start Version M_01-06-03-000
Variant Support
Supported by any AKD with extended IO.
Fieldbus Information
Fieldbus Index/Subindex Is 64 bit? Attributes Signed? Object Start Version
Modbus 1236
Description
AIN2.DEADBAND sets the deadband of the analog input 2 signal. When AIN2.DEADBANDMODE (S.
422) is set to 0, and the value of the analog input 2 is less than the value of AIN2.DEADBAND, the analog
command will be 0. When the analog input 2 is greater or equal to the AIN2.DEADBAND, then the analog
command will be generated using the scaling specified.
When AIN2.DEADBANDMODE is set to 1, the analog command is 0 if the input is less than the dead-
band value. When the input is greater than the deadband, the output is equal to (Input - Deadband) * Scal-
ing.
Related Topics
Analogeingang (S. 128)
Block Diagram for Position/Velocity Loop (pg 1)
NV Parameter
Sets the analog input 2 signal dead-
band.
V
0 to 12.5 V
0 V
Float
No 16 bit No M_01-06-03-000
KOLLMORGEN | Mai 2014 421
