AKD Benutzerhandbuch | 24.3.5 AIN2.OFFSET

24.3.5 AIN2.OFFSET

General Information
Type
Description
Units
Range
Default
Value
Data Type
Start Version M_01-06-03-000
Variants Supported
Supported by any AKD with extended IO.
Fieldbus Information
Fieldbus Index/Subindex Is 64 bit? Attributes Signed? Object Start Version
Modbus 1244
Description
AIN2.OFFSET sets the analog offset, which is added to the analog input 2 command to the drive. This
value compensates for the analog input 2 signal (AIN.VALUE (S. 414)) offset or drift.
Related Topics
Analogeingang (S. 128)
AIN2.ZERO (S. 426)
Block Diagram for Position/Velocity Loop (pg 1)
424 KOLLMORGEN | Mai 2014
NV Parameter
Sets the analog input 2 off-
set.
V
–10 to +10 V
0 V
Float
No 16 bit Yes M_01-06-03-000
