AKD Benutzerhandbuch | 24.18.7 FB3.PDIR

24.18.7 FB3.PDIR

General Information
Type
Description
Units
Range
Default
Value
Data Type
See Also
Start Version M_01-05-11-000
Variants Supported
AKD Base
AKD with Position Indexer
AKD EtherCAT
AKD CANopen
AKD BASIC
AKD SynqNet
AKD EtherNet/IP
AKD Profinet
AKD sercos ® III
AKD-N
AKD-C
Fieldbus Information
Fieldbus
Profinet
sercos ® III
Fieldbus Index/Subindex Is 64 bit? Attributes Signed? Object Start Version
Modbus 1650
Description
FB3.PDIR will change the sign and with it the direction of feedback channel 3 (FB3.P (S. 738)).
Example
If FB3.P = 35,185.932 and you set:
--> FB3.PDIR 1
then FB3.P = -35,185.932
739 KOLLMORGEN | Mai 2014
NV-Parameter
Sets the counting direction for feedback channel
3.
None
0 to 1
0
U8
N/A
Variant Supported
Address Attributes Signed?
Byte
2825 No
2 Octets
No
No
No
Yes
Yes
Yes
Yes
Yes
Yes
Yes
No
No
8-bits No M_01-06-03-000
