AKD Benutzerhandbuch | 24.7.8 CAP0.PREEDGE, CAP1.PREEDGE
The precondition edge is monitored for rising edge, falling edge, or both. The event mode logic may ignore
the precondition edge detection (trigger always uses edge detection).
The filtered trigger source has an identical feature controlled by CAP0.EDGE, CAP1.EDGE (S. 478).
Value Description
0
1
2
3
Related Topics
Verwendung der Positionserfassung (S. 98)
CAP0.EDGE, CAP1.EDGE (S. 478)
492 KOLLMORGEN | Mai 2014
Reserved
Rising
edge
Falling
edge
Both edges
