AKD Benutzerhandbuch | 24.33.16 REC.TRIGPOS
24.33.16 REC.TRIGPOS
General Information
Type
Description
Units
Range
Default
Value
Data Type
See Also
Start Version M_01-00-00-000
Variants Supported
AKD Base
AKD with Position Indexer
AKD EtherCAT
AKD CANopen
AKD BASIC
AKD SynqNet
AKD EtherNet/IP
AKD Profinet
AKD sercos ® III
AKD-N
AKD-C
Fieldbus Information
Fieldbus
Profinet
sercos ® III
Description
REC.TRIGPOS sets the trigger position in the recording buffer. The recording buffer size is defined by
REC.NUMPOINTS. The input value is a percentage of the buffer (that is, a value of 25 means saving
25% of the buffer data before the trigger occurs and 75% after it occurs). This parameter is only used
when REC.TRIGTYPE = 2 or 3.
Trigger Position
Trigger position (REC.TRIGPOS) allows you to collect data that occurs before the trigger occurs. In some
instances, you may want to see the conditions prior to the trigger. Trigger position lets you control how
much signal is collected before the trigger condition occurred .
Trigger position is specified in units of percent (%). If you specify a trigger position of x% , then x% of the
data is before 0 ms in the data time and 100-x% (the rest of the data) is at or greater than 0 ms. In the fig-
ure below, the trigger position is set to 25% (REC.TRIGPOS 25).
In the WorkBench scope, the 0 time point is clear. When collecting the data using REC.RETRIEVE or
similar commands, the time is not returned, so some caution should be used when the trigger point is
important to understand.
R/W Parameter
Sets the trigger position in the recording buffer.
%
1 to 100%
10%
Integer
REC.TRIG (S. 1045), REC.NUMPOINTS (S.
1034)
Variant Supported
Address Attributes Signed?
Byte
2361 No
2 Octets
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
