AKD Benutzerhandbuch | 24.18.2 FB3.ENCRES

24.18.2 FB3.ENCRES

General Information
Type
Description
Units
Range
Default
Value
Data Type
Start Version M_01-11-03-000
Variants Supported
AKD Base
AKD with Position Indexer
AKD EtherCAT
AKD CANopen
AKD BASIC
AKD SynqNet
AKD EtherNet/IP
AKD Profinet
AKD sercos ® III
AKD-N
AKD-C
Description
Feedback 3 is natively scaled to 4,294,967,296 counts per revolution for rotary motors, and 4,294,967,296
per motor pole pitch (MOTOR.PITCH (S. 917)) for linear motors. When FB3.ENCRES is non-zero, scal-
ing is applied on top of the native scaling.
Rotary Example:
A second feedback device is placed at the load which has a 1:4 gear ratio (motor does four revolutions per
secondary revolution). In this case, FB3.ENCRES should be 4,294,967,296 / 4 = 1,073,741,824
Linear Example:
Linear encoder resolution can be calculated as the number of encoder counts per one revolution of the
motor. For example, if a linear setup has a 10mm scale (100,000 counts/mm), and the ballscrew has a
10mm lead with no gearbox, it will result in 1,000,000 counts for every revolution of the motor shaft. For
this example, FB3.ENCRES should be set to 1,000,000.
NV Parameter
Sets the resolution of the motor encoder for feedback 3.
None
0 to 4,294,967,295
0
Integer
Variant Supported
No
No
Yes
Yes
Yes
Yes
Yes
Yes
Yes
No
No
