AKD Benutzerhandbuch | 24.24.38 IL.VVFB

24.24.38 IL.VVFB

General Information
Type
Description
Units
Range
Default
Value
Data Type
See Also
Start Version M_01-00-00-000
Variants Supported
AKD Base
AKD with Position Indexer
AKD EtherCAT
AKD CANopen
AKD BASIC
AKD SynqNet
AKD EtherNet/IP
AKD Profinet
AKD sercos ® III
AKD-N
AKD-C
Fieldbus Information
Fieldbus
Profinet
sercos ® III
Fieldbus Index/Subindex Is 64 bit? Attributes Signed? Object Start Version
Modbus 478
Description
The range for this parameter depends on whether the drive model is an MV/240 VAC or an HV/480 VAC.
The VBusScale parameter sets the drive model:
MV/240 VAC: VBusScale = 1
HV/480 VAC: VBusScale = 2
VBusScale is used for multiple parameter ranges that are model dependent, such as IL.KP.
Related Topics
Stromregelkreis (S. 149)
R/O Parameter
Reads the measured voltage on the v-winding of the
motor.
V
–1200*VBusScale to +1200*VBusScale
N/A
Integer
IL.VUFB (S. 858)
Variant Supported
Address Attributes Signed?
Word
2239 Yes
2 Octets
No
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
No
16 bit Yes M_01-03-00-000
