AKD Benutzerhandbuch | 24.28.32 MOTOR.TEMPC

24.28.32 MOTOR.TEMPC

General Information
Type
Description
Units
Range
Default
Value
Data Type
Start Version M_01-10-04-000
Variants Supported
AKD Base
AKD with Position Indexer
AKD EtherCAT
AKD CANopen
AKD BASIC
AKD SynqNet
AKD EtherNet/IP
AKD Profinet
AKD sercos ® III
AKD-N
AKD-C
Description
When the motor has a thermistor with linear characteristics (MOTOR.RTYPE = 2, 3 or 4),
MOTOR.TEMPC returns the motor temperature in degrees Celsius, which is calculated from the resist-
ance of the motor thermistor.
There is no algorithm to convert from resistance to degrees Celsius for non-linear thermistors. In this
case, MOTOR.TEMPC returns -32,768 which is an invalid temperature.
Related Topics
8.1 Motor | MOTOR.TEMP (S. 929) | MOTOR.RTYPE (S. 921)
930 KOLLMORGEN | Mai 2014
R/O Parameter
Reads the motor temperature in degrees Cel-
sius.
Degrees Celsius
-2 15 to 2 15
N/A
Integer
Variant Supported
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
No
