AKD Benutzerhandbuch | 24.10.11 DIN21.FILTER to DIN32.FILTER
Fieldbus Index/Subindex
Modbus
Description
This parameter sets the digital input filter configuration for channel x when followed with the values
defined below. DINx.FILTER retrieves this information when not followed by data.
Value
DINX.FILTER
0
DINX.FILTER
1
DINX.FILTER
2
DINX.FILTER
3
Related Topics
Digitale Eingänge und Ausgänge (S. 112)
Is 64 bit? Attributes Signed?
1310 DIN21.FILTER
1322 DIN22.FILTER
1334 DIN23.FILTER
1346 DIN24.FILTER
1358 DIN25.FILTER
1370 DIN26.FILTER
No
1382 DIN27.FILTER
1394 DIN28.FILTER
1406 DIN29.FILTER
1418 DIN30.FILTER
1430 DIN31.FILTER
1442 DIN32.FILTER
The drive digital input channel detects all input signals with
an input pulse width of ≥ 40 ns (no filtering applied).
The drive digital input channel detects all input signals with
an input pulse width of ≥ 10.24 µs, ± 0.64 µs (fast filter
applied).
The drive digital input channel detects all input signals with
an input pulse width of ≥ 163 µs, ± 10.24 µs (standard filter
applied).
The drive digital input channel detects all input signals with
an input pulse width of ≥ 2.62 ms, ± 0.16384 ms (slow filter
applied).
16 bit No
Description
