Il.foldfthresh - Kollmorgen AKD-C01007-MCEC Benutzerhandbuch

AKD Benutzerhandbuch | 24.24.11 IL.FOLDFTHRESH

24.24.11 IL.FOLDFTHRESH

General Information
Type
Description
Units
Range
Default
Value
Data Type
See Also
Start Version M_01-00-00-000
Variants Supported
AKD Base
AKD with Position Indexer
AKD EtherCAT
AKD CANopen
AKD BASIC
AKD SynqNet
AKD EtherNet/IP
AKD Profinet
AKD sercos ® III
AKD-N
AKD-C
Fieldbus Information
Fieldbus
EtherCAT COE and CAN-
open
Fieldbus
Profinet
sercos ® III
Fieldbus Index/Subindex Is 64 bit? Attributes Signed? Object Start Version
Modbus 436
Description
IL.FOLDFTHRESH is the fault level of the current foldback algorithm. If IL.IFOLD (S. 834) drops below
the value for IL.FOLDFTHRESH, then a fault is generated and the drive is disabled.
To avoid reaching the current foldback fault level, set IL.FOLDFTHRESHU well below the continuous cur-
rent value for both the drive and the motor or set the IL.FOLDFTHRESHU value to zero.
Related Topics
13.3 Stromregelkreis
830 KOLLMORGEN | Mai 2014
R/O Parameter
Reads the foldback fault level.
Arms
0 to 500 Arms
Drive peak current
(DRV.IPEAK)
Float
Foldback
Variant Supported
Index/Subindex Object Start Version
3420h/0
Address Attributes Signed?
DWord
2218 No
4 Octets
No
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
No
M_01-00-00-000
32 bit No M_01-03-00-000
