AKD Benutzerhandbuch | 24.34.5 REGEN.TYPE
24.34.5 REGEN.TYPE
General Information
Type
Function
WorkBench Location (Screen/Dialog
Box)
Units
Range
Default Value
Data Type
See Also
Start Version
Variants Supported
AKD Base
AKD with Position Indexer
AKD EtherCAT
AKD CANopen
AKD BASIC
AKD SynqNet
AKD EtherNet/IP
AKD Profinet
AKD sercos ® III
AKD-N
AKD-C
Fieldbus Information
Fieldbus
EtherCAT COE and CAN-
open
Fieldbus
Profinet
sercos ® III
Fieldbus Index/Subindex Is 64 bit? Attributes Signed? Object Start Version
Modbus 742
Description
You can specify a user-defined external regen resistor, select an internal regen resistor, or choose from a
list of predefined regen resistors. The values for REGEN.TYPE are shown below:
Type
–1
0
1061 KOLLMORGEN | Mai 2014
Variant
Index/Subindex Object Start Version
3412h/0
Address Attributes Signed?
Byte
2371
2 Octets
No
Description
External user-defined regen
resistor
Internal regen resistor
NV Parameter
Sets the regen resistor type.
Power/Regen Resistor
Type
N/A
–1 to 0
0
Integer
N/A
M_01-00-00-000
Supported
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
No
Yes
M_01-00-00-000
Yes
8 bit Yes M_01-03-00-000
