AKD Benutzerhandbuch | 24.34.4 REGEN.TEXT
24.34.4 REGEN.TEXT
General Information
Type
Description
Units
Range
Default
Value
Data Type
See Also
Start Version M_01-00-00-000
Variants Supported
AKD Base
AKD with Position Indexer
AKD EtherCAT
AKD CANopen
AKD BASIC
AKD SynqNet
AKD EtherNet/IP
AKD Profinet
AKD sercos ® III
AKD-N
AKD-C
Fieldbus Information
Fieldbus
EtherCAT COE and CAN-
open
Fieldbus
Profinet
sercos ® III
Fieldbus Index/Subindex Is 64 bit? Attributes Signed? Object Start Version
Modbus 740
Description
REGEN.TEXT is the time-to-fault when input power steps from 0 to 150% of REGEN.WATTEXT.
REGEN.TEXT sets the thermal time constant of the algorithm used to protect the regeneration resistor
from overheating and failing. The drive's regen resistor protection algorithm continuously calculates the
power dissipated in the resistor and processes that power value through a single pole low pass filter to
model the regen resistor's thermal inertia. When the filtered regen power on the output of the filter
(REGEN.POWERFILTERED) exceeds REGEN.WATTEXT, a fault occurs. REGEN.TEXT sets the time
constant of this thermal inertial filter = (REGEN.TEXT/1.1).
1059 KOLLMORGEN | Mai 2014
R/W Parameter
Sets the external regen resistor thermal protection time con-
stant.
Seconds
0.1 to 1,200 Seconds
100 Seconds
Float
REGEN.WATTEXT (S. 1063), REGEN.REXT (S. 1058)
Variant Supported
Index/Subindex Object Start Version
3415h/0
Address Attributes Signed?
DWord
2370 No
4 Octets
No
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
No
Yes
M_01-00-00-000
32 bit No M_01-03-00-000
