AKD Benutzerhandbuch | 24.46.3 VL.ARTYPE1 TO VL.ARTYPE4
Parameter
VL.ARTYPE1
VL.ARTYPE2
VL.ARTYPE3
VL.ARTYPE4
Fieldbus Index/Subindex
Modbus
Description
These parameters indicate the method used to calculate the biquad coefficients VL.ARPFx, VL.ARPQx,
VL.ARZFx, and VL.ARZQx. A value of 0 indicates that the coefficients are set directly. This parameter
has no effect on the filter itself, but is only used to determine the original design parameters. Currently,
only the value of 0 is supported.
Related Topics
13.4 Geschwindigkeitsregelkreis
Fieldbus Address Attributes Signed?
Profinet
2412
sercos ® III
Profinet
2413
sercos ® III
Profinet
2414
sercos ® III
Profinet
2415
sercos ® III
Is 64 bit? Attributes Signed? Object Start Version
824 VL.ARTYPE1
826 VL.ARTYPE2
No
828 VL.ARTYPE3
830 VL.ARTYPE4
Byte
2 Octets
Byte
2 Octets
No
Byte
2 Octets
Byte
2 Octets
8 bit No M_01-03-00-000
