AKD Benutzerhandbuch | 24.45.1 VBUS.HALFVOLT
24.45.1 VBUS.HALFVOLT
General Information
Type
Description
Units
Range
Default
Value
Data Type
See Also
Start Version M_01-04-01-000
Variants Supported
AKD Base
AKD with Position Indexer
AKD EtherCAT
AKD CANopen
AKD BASIC
AKD SynqNet
AKD EtherNet/IP
AKD Profinet
AKD sercos ® III
AKD-N
AKD-C
Fieldbus Information
Fieldbus
Profinet
sercos ® III
Fieldbus Index/Subindex Is 64 bit? Attributes Signed?
Modbus 1218
Description
This parameter is used in order to change some specific voltage thresholds in order to allow HV (high volt-
age) drives working with MV (medium voltage) thresholds and to allow MV (medium voltage) drives work-
ing with LV (low voltage) thresholds.
When the VBUS.HALFVOLT value is changed, the revised thresholds take effect immediately.
The VBUS.HALFVOLT only affects HV and MV drives.
Value Description
0 The original voltage thresholds are used for the functions mentioned below.
1 Setting the parameter to 1 on a HV Drive causes the AKD to use the voltage thresholds of an MV
drive for the functions mentioned below. Setting the parameter to 1 on a MV drive causes the AKD
to use the voltage thresholds of a LV drive for the functions mentioned below.
This parameter has an impact on the following voltage-thresholds:
1131 KOLLMORGEN | Mai 2014
NV Parameter
Changes voltage thresholds for HV and MV Drives
N/A
0 to 1
0
Integer
N/A
Variant Supported
Address Attributes Signed?
Byte
2609 No
2 Octets
No
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
8 bit No
