AKD Benutzerhandbuch | 24.43.3 UNIT.LABEL
24.43.3 UNIT.LABEL
General Information
Type
Description
Units
Range
Default
Value
Data Type
See Also
Start Version M_01-00-00-000
Variants Supported
AKD Base
AKD with Position Indexer
AKD EtherCAT
AKD CANopen
AKD BASIC
AKD SynqNet
AKD EtherNet/IP
AKD Profinet
AKD sercos ® III
AKD-N
AKD-C
Description
If you define a special position unit with UNIT.PLINEAR (S. 1116) and UNIT.POUT (S. 1118), then you
can give this unit a descriptive name. You can name the unit anything you wish, as long as the name is lim-
ited to 16 characters and includes no spaces. The label used for velocity and acceleration are in terms of
this descriptive name.
This parameter is descriptive only and does not influence drive internal functions in any way.
Related Topics
Auswählen von Einheiten für Ihre Anwendung (S. 107)
NV Parameter
Sets user-defined name for user-defined position
units.
N/A
Maximum 16 characters, no spaces
Benutzerspezifische Einheiten (S. 108)
String
UNIT.PLINEAR (S. 1116), UNIT.POUT (S. 1118)
Variant Supported
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
No
