AKD Benutzerhandbuch | 24.46.11 VL.FBFILTER
24.46.11 VL.FBFILTER
General Information
Type
Description
Units
Range
Default
Value
Data Type
See Also
Start Ver-
sion
Variants Supported
AKD Base
AKD with Position Indexer
AKD EtherCAT
AKD CANopen
AKD BASIC
AKD SynqNet
AKD EtherNet/IP
AKD Profinet
AKD sercos ® III
AKD-N
AKD-C
Fieldbus Information
Fieldbus
EtherCAT COE and CAN-
open
Fieldbus
Profinet
sercos ® III
Fieldbus Index/Subindex Is 64 bit?
Modbus 858
Description
This parameter returns the same value as VL.FB (S. 1157), filtered through a 10 Hz filter.
Related Topics
13.4 Geschwindigkeitsregelkreis
R/O Parameter
Filters VL.FB (S. 1157) value; active in opmodes 1 (velocity) and 2 (position)
only.
Depends on UNIT.VROTARY (S. 1124) or UNIT.VLINEAR (S. 1122)
Rotary: rpm, rps, deg/s, (custom units)/s, rad/s
Linear: counts/s, mm/s, µm/s, (custom units)/s
N/A
N/A
Float
VL.FB (S. 1157)
M_01-00-00-000
Variant Supported
Index/Subindex Object Start Version
3407h/1
Parameter Address Attributes Signed?
VL.FBFILTER_32 2429
Yes low 32 bit word Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
No
M_01-00-00-000
DWord
Yes
8 Octets
Attributes Signed? Object Start Version
M_01-03-00-000
