AKD Benutzerhandbuch | 24.47.6 WS.DISTMAX
24.47.6 WS.DISTMAX
General Information
Type
Description
Units
Range
Default
Value
Data Type
See Also
Start Version M_01-01-00-101, M_01-02-00-000
Variants Supported
AKD Base
AKD with Position Indexer
AKD EtherCAT
AKD CANopen
AKD BASIC
AKD SynqNet
AKD EtherNet/IP
AKD Profinet
AKD sercos ® III
AKD-N
AKD-C
Fieldbus Information
Fieldbus
EtherCAT COE and CAN-
open
Fieldbus
Profinet
sercos ® III
Fieldbus Index/Subindex Is 64 bit? Attributes Signed? Object Start Version
Modbus 892
Description
This parameter sets the maximum movement that is allowed for finding commutation. If this value is too
small, F F475 (S. 287), "Wake and Shake. Too much movement", may occur before wake and shake is fin-
ished. The bigger this value, the more movement is allowed for wake and shake. This value is application
dependent.
Related Topics
Wake&Shake Übersicht (S. 78)
1188 KOLLMORGEN | Mai 2014
R/W Parameter
Sets maximum movement allowed for wake and
shake.
deg (position units)
0 to 90 deg
15 deg
S64
N/A
Variant Supported
Index/Subindex Object Start Version
3494h/2
Address Attributes Signed?
DWord
2446 Yes
8 Octets
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
No
M_01-00-00-000
64 bit Yes M_01-03-00-000
