AKD Benutzerhandbuch | 24.46.27 VL.THRESH
24.46.27 VL.THRESH
General Information
Type
Description
Units
Range
Default
Value
Data Type
Start Version M_01-00-00-000
Variants Supported
AKD Base
AKD with Position Indexer
AKD EtherCAT
AKD CANopen
AKD BASIC
AKD SynqNet
AKD EtherNet/IP
AKD Profinet
AKD sercos ® III
AKD-N
AKD-C
NV Parameter
Sets the user over speed fault level.
Depends on UNIT.VROTARY (S. 1124) or UNIT.VLINEAR (S.
1122)
Rotary: rpm, rps, deg/s, custom units/s, rad/s
Linear: counts/s, mm/s, µm/s, custom units/s
Rotary:
0.000 to 15,000.000 rpm
0.000 to 250.000 rps
0.000 to 90,000.000 deg/s
0.000 to 1,250.000 custom units/s
0.000 to 1,570.796 rad/s
Linear:
0.000 to 1,073,741,824,000.000 counts/s
0.000 to 250.000*MOTOR.PITCH (S. 917) mm/s
0.000 to 250,000.000*MOTOR.PITCHMOTOR.PITCH (S. 917)µm/s
0.000 to 1,250.000 custom units/s
Rotary:
3,600 rpm
60 rps
21,600.000 deg/s
300.000 custom units/s
376.991 rad/s
Linear:
0.060 counts/s
60.000*MOTOR.PITCH (S. 917) mm/s
60,000.04*MOTOR.PITCHMOTOR.PITCH (S. 917)µm/s
300.000 custom units/s
Float
Variant Supported
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
No
