AKD Benutzerhandbuch | 24.46.27 VL.THRESH
Fieldbus Information
Fieldbus
EtherCAT COE and CAN-
open
Fieldbus
Profinet
sercos ® III
Fieldbus Index/Subindex Is 64 bit?
Modbus 888
Description
VL.THRESH sets the user overspeed fault threshold. This threshold becomes the overall overspeed fault
threshold (VL.VFTHRESH) if it is less than the motor speed threshold (1.2 x MOTOR.VMAX), and for
MOTOR.TYPE = 6 if it is less than the motor back EMF overspeed threshold ((1.02 x 1000 x
VBUS.OVFTHRESH) / (MOTOR.KE x sqrt(2))).
The value is considered an absolute value, hence it applies for both negative and positive velocities.
Example
VL.THRESH is set to 600 rpm. A velocity (VL.FB (S. 1157)) of 700 rpm will generate an over speed fault.
Related Topics
13.4 Geschwindigkeitsregelkreis | VL.CMD (S. 1152) | VL.CMDU (S. 1154) | VL.VFTHRESH (S. 1180)
1179 KOLLMORGEN | Mai 2014
Index/Subindex Object Start Version
3627h/0
Parameter Address Attributes Signed?
VL.THRESH_32 2444
Yes low 32 bit word Yes
M_01-00-00-000
DWord
Yes
8 Octets
Attributes Signed? Object Start Version
M_01-03-00-000
