AKD Benutzerhandbuch | 24.42.2 TEMP.POWER1 to TEMP.POWER3
24.42.2 TEMP.POWER1 to TEMP.POWER3
General Information
Type
Description
Units
Range
Default
Value
Data Type
Start Version M_01-09-00-000
Variants Supported
AKD Base
AKD with Position Indexer
AKD EtherCAT
AKD CANopen
AKD BASIC
AKD SynqNet
AKD EtherNet/IP
AKD Profinet
AKD sercos ® III
AKD-N
AKD-C
Fieldbus Information
TEMP.POWER1
TEMP.POWER2
TEMP.POWER3
Fieldbus
Modbus
Description
Reads the temperature of the power board(s) temperature sensor(s). Most AKDs have only one power
board sensor which is read by TEMP.POWER1.
Related Topics
DRV.TEMPERATURES (S. 649) | TEMP.CONTROL (S. 1107)
1108 KOLLMORGEN | Mai 2014
R/O Parameter
Reads the temperature of the power board(s) temperature sensor
(s).
Degrees Celsius
-127 to 128
N/A
Integer
Variant
Parameter Fieldbus
Profinet
sercos ® III
Profinet
sercos ® III
Profinet
sercos ® III
Parameter Index/Subindex Is 64 bit? Attributes Signed?
TEMP.POWER1 1750
TEMP.POWER2 1752
TEMP.POWER3 1753
Supported
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Address Attributes Signed?
Word
2875
2 Octets
Word
2876 Yes
2 Octets
Word
2877
2 Octets
No 16-bit Yes
