25.12.5 DOUT1.PARAM AND DOUT2.PARAM

General Information
Type
Description
Units
Range
Default
Value
Data Type
See Also
Start Version M_01-00-00-000
Variants Supported
AKD BASIC
AKD SynqNet
AKD EtherNet/IP
Fieldbus Information
Fieldbus Index/Subindex
Modbus
Description
DOUT1.PARAM and DOUT2.PARAM set the extra parameter needed for the digital outputs calculations,
respectively.
Range
DOUTx.PARAM is used for various Digital Output modes. This causes the parameter's range to change
based on the current Digital Output mode selected with the corresponding DOUTx.MODE.
Below is a list of the possible range for each Digital Output Mode.
If an output mode is not listed, then the default range of 0 is used.
Input
Mode
4
5
6
12
13
NV Parameter
Sets extra parameters for the digital outputs.
N/A
0
Note: Range changes based on Digital Output Mode. See
below.
0
Integer
N/A
Variant
198 DOUT1.PARAM
208 DOUT2.PARAM
Min Max
Position Position
Min Max
Position Position
Min Max
Position Position
Min Max
Velocity
0
Max
Velocity
0
Max
DOUT1.PARAM DOUT2.PARAM
Supported Supported
√
√ N/A
√
Is 64 bit? Attributes Signed? Object Start Version
Yes 64 bit Yes
Notes
This value changes based on user selected position
units.
This value changes based on user selected position
units.
This value changes based on user selected position
units.
This value changes based on user selected velocity
units.
This value changes based on user selected velocity
units.
√
√
M_01-03-00-000
