AKD Benutzerhandbuch | 25.16.1 FB1.BISSBITS

25.16.1 FB1.BISSBITS

General Information
Type
Description
Units
Range
Default
Value
Data Type
See Also
Start Ver-
sion
Variants Supported
AKD BASIC
AKD SynqNet
AKD EtherNet/IP
Fieldbus Information
Fieldbus Index/Subindex Is 64 bit? Attributes Signed? Object Start Version
Modbus 280
Description
FB1.BISSBITS specifies the number of BiSS sensor (position) bits for the BiSS Mode C encoder in use.
Typically the value is either 26 or 32 for a BiSS Mode C Renishaw encoder. The required value for this
parameter is provided by the feedback device manufacturer for the particular device being used.
Related Topics
Rückführung 1 (s: 69)
598 KOLLMORGEN | Mai 2013
NV Parameter
Specifies the number of Biss Sensor (Position) Bits for the BiSS Mode C
encoder in use.
bits
0 to 64 bits
32 bits
Integer
FB1.SELECT (s: 628), FB1.IDENTIFIED (s: 608)
M_01-01-00-100 and M_01-01-03-000
Variant Supported
No 8 bit
√
√
√
No M_01-03-00-000
