AKD Benutzerhandbuch | 25.24.31 IL.MIFOLD

25.24.31 IL.MIFOLD

General Information
Type
Description
Units
Range
Default
Value
Data Type
See Also
Start Version M_01-00-00-000
Variants Supported
AKD BASIC
AKD SynqNet
AKD EtherNet/IP
Fieldbus Information
Fieldbus
EtherCAT COE and CAN-
open
Fieldbus Index/Subindex Is 64 bit? Attributes Signed? Object Start Version
Modbus 470
Description
IL.MIFOLD sets the output of the motor foldback algorithm. It is an artificial current, which can be higher
or lower than the motor peak current. When IL.MIFOLD becomes lower than the existing current limit
(IL.LIMITP (s: 736)) it becomes the active current limit.
IL.MIFOLD decreases when the actual current is higher than motor continuous current and increases (up
to a certain level) when the actual current is lower than the motor continuous current.
Related Topics
13.3 Stromregelkreis
R/O Parameter
Sets the motor foldback current
limit.
A
0 to 2147483.647 A
N/A
Float
Foldback
Variant Supported
Index/Subindex Object Start Version
35A4h/0
No 32 bit
√
√
√
M_01-00-00-000
No M_01-03-00-000
KOLLMORGEN | Mai 2013 742
