AKD Benutzerhandbuch | 25.24.9 IL.FOLDFTHRESH

25.24.9 IL.FOLDFTHRESH

General Information
Type
Description
Units
Range
Default
Value
Data Type
See Also
Start Version M_01-00-00-000
Variants Supported
AKD BASIC
AKD SynqNet
AKD EtherNet/IP
Fieldbus Information
Fieldbus
EtherCAT COE and CAN-
open
Fieldbus Index/Subindex Is 64 bit? Attributes Signed? Object Start Version
Modbus 436
Description
IL.FOLDFTHRESH is the fault level of the current foldback algorithm. If IL.IFOLD (s: 724) drops below
the value for IL.FOLDFTHRESH, then a fault is generated and the drive is disabled.
To avoid reaching the current foldback fault level, set IL.FOLDFTHRESHU well below the continuous cur-
rent value for both the drive and the motor or set the IL.FOLDFTHRESHU value to zero.
Related Topics
13.3 Stromregelkreis
R/O Parameter
Reads the foldback fault level.
Arms
0 to 500 Arms
Drive peak current
(DRV.IPEAK)
Float
Foldback
Variant Supported
Index/Subindex Object Start Version
3420h/0
No 32 bit
√
√
√
M_01-00-00-000
No M_01-03-00-000
KOLLMORGEN | Mai 2013 720
