AKD Benutzerhandbuch | 25.27.5 MODBUS.POUT

25.27.5 MODBUS.POUT

General Information
Type
Description
Units
Range
Default
Value
Data Type
Start Version M_01-04-00-000
Variants Supported
AKD BASIC
AKD SynqNet
AKD EtherNet/IP
Fieldbus Information
Fieldbus Index/Subindex Is 64 bit? Attributes Signed?
Modbus 976
Description
MODBUS.PIN (s: 765) and MODBUS.POUT are used to apply User specified Units to the feedback
values retrieved over Modbus.
To use this parameter correctly, first the MODBUS.PSCALE (s: 767) must be known. This value deter-
mines the resolution per revolution of the motor for Modbus. Then the ratio of MODBUS.POUT/MOD-
BUS.PIN (s: 765) is applied to convert counts/rev into User Units/rev.
Example: Use Modbus Scaling to return feedback in Radians
MODBUS.PSCALE = 16 (65536 counts/rev or pole pitch)
MODBUS.PIN = 5215189
MODBUS.POUT = 500000
If the motor is currently resting with a Modbus raw position 36,462 Counts (MODBUS.PSCALE (s: 767) is
set to return 65,536 per rev) andthe user requests the position using PL.FB over Modbus, the position will
be returned as:
36,462 * 500000 / 5215189 = 3495 (Radians * 1000)
Which equals 3.495 Radians
Related Topics
MODBUS.PSCALE (s: 767)
MODBUS.PIN (s: 765)
Encoder-Emulation (s: 79)
766 KOLLMORGEN | Mai 2013
R/W
Gets / Sets the Modbus User Units Output param-
eter.
N/A
1 to 4294967295
1
Integer
Variant Supported
No 32 bit
N/A
N/A
√
No
