AKD Benutzerhandbuch | 25.31.8 PLS.WIDTH1 TO PLS.WIDTH8

25.31.8 PLS.WIDTH1 TO PLS.WIDTH8

General Information
Type
Description Programmable Limit Switch Width
Units
Range
Default
Value
Data Type
See Also
Start Ver-
sion
Data Type
Variants Supported
AKD BASIC
AKD SynqNet
AKD EtherNet/IP
Fieldbus Information
Fieldbus
EtherCAT COE and
CANopen
Fieldbus Index/Subindex
Modbus
Description
871 KOLLMORGEN | Mai 2013
R/W parameter
Depends on UNIT.PROTARY or UNIT.PLINEAR
N/A
0
Float
PLS.EN, PLS.RESET, PLS.STATE, PLS.UNITS, PLS.MODE, PLS.P1 TO
PLS.P8, PLS.T1 TO PLS T8
M_01-02-03-000
AKD BASIC Information
Integer
Variant
Index/Subindex
34A1h/1
34A1h/2
34A1h/3
34A1h/4
34A1h/5
34A1h/6
34A1h/7
34A1h/8
676 PLS.WIDTH1
680 PLS.WIDTH2
684 PLS.WIDTH3
688 PLS.WIDTH4
692 PLS.WIDTH5
696 PLS.WIDTH6
700 PLS.WIDTH7
704 PLS.WIDTH8
Supported
√
√
√
Object Start
Version
PLS.WIDTH1
PLS.WIDTH2
PLS.WIDTH3
PLS.WIDTH4
M_01-02-
03-000
PLS.WIDTH5
PLS.WIDTH6
PLS.WIDTH7
PLS.WIDTH8
Is 64
Attributes Signed?
bit?
Yes 64 bit Yes
Object Start Ver-
sion
M_01-03-00-000
