AKD Benutzerhandbuch | 25.17.1 FB2.ENCRES

25.17.1 FB2.ENCRES

General Information
Type
Description
Units
Range
Default
Value
Data Type
See Also
Start Ver-
sion
Variants Supported
AKD BASIC
AKD SynqNet
AKD EtherNet/IP
Fieldbus Information
Fieldbus Index/Subindex Is 64 bit? Attributes Signed?
Modbus 984
Description
This parameter sets the feedback 2 (FB2) resolution and defines how many counts input into the sec-
ondary feedback will be considered a full revolution.
In AKD BASIC FB2.ENCRES also defines the resolution of the virtual encoder when using the CAMVM
commands. A runtime error will occur if the you use the CAMVM commands without defining a resolution
in FB2.ENCRES. If a real encoder and a virtual encoder are both used, the resolution for the virtual
encoder will be that of the real encoder.
Related Topics
Rückführung 2 (s: 78)
636 KOLLMORGEN | Mai 2013
NV Parameter
Sets the secondary feedback (FB2) resolution (also defines resolution of virtual
encoder in AKD BASIC).
counts/rev
0 to 262,140 counts/rev
0
Integer
FB2.MODE, FB2.SOURCE (s: 642)
M_01-03-00-000
Variant Supported
No 32 bit
√
√
√
No
