AKD Benutzerhandbuch | 25.13.48 DRV.NVCHECK

25.13.48 DRV.NVCHECK

General Information
Type
Description
Units
Range
Default
Value
Data Type
See Also
Start Version M_01-04-12-000
Variants Supported
AKD BASIC
AKD SynqNet
AKD EtherNet/IP
Fieldbus Information
EtherCat COE and
CANopen
Fieldbus Index/Subindex Is 64 bit?
Modbus 1042
Description
DRV.NVCHECK returns a checksum of all the drives NV parameters. This parameter can be used to
detect changes in parameters.
In some applications a master device needs to confirm the AKD drive contains an expected set of drive
parameters. Reading and checking all the drive parameters individually is viable but this would be a long
process involving many reads over the network. DRV.NVCHECK is a checksum on all the NV param-
eters and this parameter can be read in a single transaction. DRV.NVCHECK will return the same number
if all the drive parameters match. If any of the drive parameters are changed then DRV.NVCHECK will
return a different value.
569 KOLLMORGEN | Mai 2013
R/O Parameter
NV Parameter Check-
sum
None
N/A
N/A
Integer
DRV.NVLIST
Variant
Fieldbus Index/Subindex
2019h/0
Yes
Supported
N/A
√
√
Object Start Version
M_01-04-12-000
Attributes Signed? Object Start Version
low 32 bit word No M_01-04-12-000
