AKD Benutzerhandbuch | 25.4.2 AIO.PSCALE
Fieldbus Index/Subindex Is 64 bit? Attributes Signed? Object Start Version
Modbus 1262 Yes 64-bit No M_01-06-03-000
Description
AIO.PSCALE is an analog position scale factor that scales:
1. The analog input (AIN.VALUE (s: 398)) for DRV.OPMODE (s: 574) = 2 , DRV.CMDSOURCE (s: 522)
= 3 (analog position mode)
2. The analog output (AOUT.VALUE (s: 424)) for AOUT.MODE (s: 419) = 6, or 7. (actual position or posi-
tion error) per 10 V of analog input or output.
