AKD Benutzerhandbuch | 25.8.1 CAP0.EDGE, CAP1.EDGE

25.8.1 CAP0.EDGE, CAP1.EDGE

General Information
Type
Description
Units
Range
Default
Value
Data Type
See Also
Start Version M_01-00-00-000
Variants Supported
AKD BASIC
AKD SynqNet
AKD EtherNet/IP
Fieldbus Information
Field-
bus
Modbus 54
Description
The filtered trigger source is monitored for rising edge, falling edge, or both edges. The event mode logic
may ignore the precondition edge detection; however, the trigger always uses edge detection.
The precondition logic has an identical feature controlled by CAP0.PREEDGE, CAP1.PREEDGE (s:
462).
Value Description
0
1
2
3
Related Topics
Verwendung der Positionserfassung (s: 88)
454 KOLLMORGEN | Mai 2013
NV Parameter
Selects the capture edge.
N/A
1 to 3
1
U8
CAP0.PREEDGE, CAP1.PREEDGE (s:
462)
Variant
Index/Subindex
CAP0.EDGE
80 CAP1.EDGE
Reserved
Rising
edge
Falling
edge
Both edges
Supported
√
√
√
Is 64 bit? Attributes
No 8 bit
Object
Start
Signed?
Ver-
sion
M_01-
No
03-00-
000
