AKD Benutzerhandbuch | 25.33.2 REGEN.POWERFILTERED

25.33.2 REGEN.POWERFILTERED

General Information
Type
Description Returns a filtered version of REGEN.POWER .
Units
Range
Default
Value
Data Type
Start Ver-
sion
Fieldbus Information
Fieldbus Index/Subindex Is 64 bit? Attributes Signed?
Modbus 1736
Description
This parameter returns a filtered value of REGEN.POWER. A single order lowpass of 1/REGEN.TEXT
Hz is applied to generate REGEN.POWERFILTERED.
If REGEN.POWERFILTERED exceeds the value of REGEN.WATTEXT, Fault 521 (Regen overpower)
will be generated.
This keyword may be recorded in the scope screen for analysis.
Example
REGEN.TEXT = 10 (seconds)
Lowpass Filter Frequence = 1/10 seconds = 0.1 Hz
REGEN.POWERFILTERED = REGEN.POWER * 0.1Hz lowpass
Related Topics
REGEN.POWER (s: 897) | REGEN.TEXT (s: 900) | REGEN.WATTEXT (s: 903)
R/O parameter
Watt
0 to REGEN.WATTEXT
0
Integer
M_01-07-01-000
Yes 64-bit No
KOLLMORGEN | Mai 2013 898
