AKD Benutzerhandbuch | 25.28.13 MOTOR.KE

25.28.13 MOTOR.KE

General Information
Type
Description
Units
Range
Default
Value
Data Type
See Also
Start Version M_01-03-06-000
Variants Supported
AKD BASIC
AKD SynqNet
AKD EtherNet/IP
Fieldbus Information
Fieldbus Index/Subindex Is 64 bit? Attributes Signed?
Modbus 1216
Description
MOTOR.KE defines the back EMF constant for the motor. The back EMF constant defines how much
voltage is generated at the motors coils. The relationship between MOTOR.KE and speed is described by
the following equation:
Coil Voltage = MOTOR.KE * VL.FB
Where:
VL.FB is in units of krpm for rotary motors and in units of m/s for linear motors
Related Topics
Motor (s: 65)
785 KOLLMORGEN | Mai 2013
NV Parameter
Sets the motor back EMF con-
stant.
Vpeak/krpm for Rotary Motors
Vpeak/m/s for Linear Motors
0.0 to 100,000
0
Float
N/A
Variant
No
This parameter is automatically configured for Kollmorgen motors when MOTOR.A-
UTOSET=1.
Supported
√
√
N/A
32 bit No
