AKD Benutzerhandbuch | 25.32.20 REC.TRIGVAL

25.32.20 REC.TRIGVAL

General Information
Type
Description Sets the trigger value.
Units
Range
Default
Value
Data Type
See Also
Start Ver-
sion
Variants Supported
AKD BASIC
AKD SynqNet
AKD EtherNet/IP
Fieldbus Information
Fieldbus Index/Subindex Is 64 bit? Attributes Signed? Object Start Version
Modbus 730
Description
REC.TRIGVAL is the value that must be met by REC.TRIGPARAM for the trigger to occur. The units of
this parameter are set according to the units of REC.TRIGPARAM.
Related Topics
Oszilloskop (s: 241)
R/W Parameter
The units of the parameter are chosen according to the unit type.
0 to 2
0
Integer
REC.TRIG (s: 888), REC.TRIGPARAM, REC.TRIGVAL, REC.TRIGSLOPE,
REC.TRIGPOS
M_01-00-00-000
Variant Supported
Yes 64 bit
N/A
√
√
Yes M_01-03-00-000
