AKD Benutzerhandbuch | 25.24.10 IL.FOLDFTHRESHU

25.24.10 IL.FOLDFTHRESHU

General Information
Type
Description
Units
Range
Default
Value
Data Type
See Also
Start Version M_01-00-00-000
Variants Supported
AKD BASIC
AKD SynqNet
AKD EtherNet/IP
Fieldbus Information
Fieldbus
EtherCAT COE and CAN-
open
Fieldbus Index/Subindex Is 64 bit? Attributes Signed? Object Start Version
Modbus 438
Description
IL.FOLDFTHRESHU is the fault level of the current foldback algorithm. The value of IL.FOLDFTHRESH
is the minimum of DRV.IPEAK (s: 560), MOTOR.IPEAK (s: 784), and IL.FOLDFTHRESHU.
Related Topics
13.3 Stromregelkreis
721 KOLLMORGEN | Mai 2013
NV Parameter
Sets the user value for the foldback fault
level.
Arms
0 to 500 Arms
Drive peak current (DRV.IPEAK)
Float
IL.FOLDFTHRESH (s: 720), Foldback (s:
83)
Variant Supported
Index/Subindex Object Start Version
3421h/0
No 32 bit
N/A
√
√
M_01-00-00-000
Yes M_01-03-00-000
