AKD Benutzerhandbuch | 25.28.33 MOTOR.VRATED

25.28.33 MOTOR.VRATED

General Information
Type
Description
Units
Range
Default
Value
Data Type
See Also
Start Version M_01-03-00-000
Variants Supported
AKD BASIC
AKD SynqNet
AKD EtherNet/IP
Fieldbus Information
Fieldbus
EtherCAT COE and CAN-
open
Fieldbus Index/Subindex Is 64 bit? Attributes Signed? Object Start Version
Modbus 1678
Description
This parameter configures the drive for the rated velocity of the induction motor as indicated on the name-
plate.
MOTOR.VRATED is used to calculate the constant volts per Hertz characteristics of the drive and motor.
If MOTOR.AUTOSET = 1 and FB1.MEMVER > 0.01, this parameter will be auto-
matically configured for KOLLMORGEN motors.
Related Topics
NV Parameter
Sets the motor rated velocity (not maximum velocity)
Depends on or
Rotary: rpm, rps, deg/s, custom units/s, rad/s
Linear: counts/s, mm/s, µm/s, custom units/s
Rotary:
0.000 to 15,000.000 rpm
0.000 to 250.000 rps
0.000 to 90,000.000 deg/s
0.000 to 1,250.000 custom units/s
0.000 to 1,570.796 rad/s
Linear:
0.000 to 1,073,741,824,000.000 counts/s
0.000 to 8,000.000 mm/s
0.000 to 8,000,000.000 µm/s
0.000 to 1,250.000 custom units/s
0 rpm
U16
MOTOR.VOLTRATED (s: 805), MOTOR.VOLTMIN (s:
804)
Variant Supported
Index/Subindex Object Start Version
3457h/1
Yes 64-bit
N/A
√
N/A
M_01-03-00-000
Yes M_01-06-03-000
KOLLMORGEN | Mai 2013 806
