AKD Benutzerhandbuch | 25.32.4 REC.GAP

25.32.4 REC.GAP

General Information
Type
Description
Units
Range
Default
Value
Data Type
See Also
Start Version M_01-00-00-000
Variants Supported
AKD BASIC
AKD SynqNet
AKD EtherNet/IP
Fieldbus Information
Fieldbus Index/Subindex Is 64 bit? Attributes Signed? Object Start Version
Modbus 712
Description
REC.GAP specifies the gap between consecutive samples. The recording base rate is 16 kHz, thus a
gap of 1 means that a sample is recorded every 62.5 µs.
Related Topics
Oszilloskop (s: 241)
R/W Parameter
Specifies the gap between consecutive sam-
ples.
N/A
1 to 65,535
1
Integer
REC.TRIG (s: 888)
Variant Supported
No 16 bit
N/A
√
√
No M_01-03-00-000
KOLLMORGEN | Mai 2013 877
