AKD Benutzerhandbuch | 25.4.3 AIO.VSCALE

25.4.3 AIO.VSCALE

General Information
Type
Description Sets velocity scale factor.
Units
Range
Default
Value
Data Type
See Also
Start Ver-
sion
End Ver-
sion
Variants Supported
AKD BASIC
AKD SynqNet
AKD EtherNet/IP
Fieldbus Information
NV Parameter
Depends on UNIT.VROTARY (s: 940) or UNIT.ACCLINEAR (s: 932)
Rotary: rpm/V, rps/V, (deg/s)/V, [(Benutzerspezifische Einheiten (s: 97))/s]/V,
(rad/s)/V
Linear: counts/s/V, (mm/s)/V, (um/s)/V, [(Benutzerspezifische Einheiten (s:
97))/s]/V
Rotary:
0.060 to 60,000 rpm/V
0.001 to 1,000 rps/V
0.359 to 360,000 (deg/s)/V
0.005 to 5,000 [(Benutzerspezifische Einheiten (s: 97))/s]/V
0.006 to 6,283.186 (rad/s)/V
Linear:
0.001 to 1.000 counts/s/V
0.001*MOTOR.PITCH (s: 790) to 1,000.000*MOTOR.PITCH (s: 790) (mm/s)
/V
0.998*MOTOR.PITCH (s: 790) to 1,000,000.000*MOTOR.PITCH (s: 790)
(um/s)/V
0.005 to 5,000 [(Benutzerspezifische Einheiten (s: 97))/s]/V
Rotary:
0.060 rpm/V
0.001 rps/V
0.359 (deg/s)/V
0.005 [(Benutzerspezifische Einheiten (s: 97))/s]/V
0.006 (rad/s)/V
Linear:
0.001 counts/s/V
0.001*MOTOR.PITCH (s: 790) (mm/s)/V
0.998*MOTOR.PITCH (s: 790) (um/s)/V
0.005 to 5,000 [(Benutzerspezifische Einheiten (s: 97))/s]/V
Float
Analog Input Block Diagram
M_01-00-00-000
M_01-01-01-000
Variant Supported
N/A
N/A
N/A
