AKD Benutzerhandbuch | 25.3.5 AIN2.OFFSET

25.3.5 AIN2.OFFSET

General Information
Type
Description
Units
Range
Default
Value
Data Type
See Also
Start Version M_01-06-03-000
Variants Supported
Supported by any AKD with extended IO.
Fieldbus Information
Fieldbus Index/Subindex Is 64 bit? Attributes Signed? Object Start Version
Modbus 1244
Description
AIN2.OFFSET sets the analog offset, which is added to the analog input 2 command to the drive. This
value compensates for the analog input 2 signal (AIN.VALUE (s: 398)) offset or drift.
Related Topics
Analogeingang (s: 117)
Blockschaltbild für den Positions-/Geschwindigkeitsregelkreis (s: 328) (for the drive controller envi-
ronment).
407 KOLLMORGEN | Mai 2013
NV Parameter
Sets the analog input 2 offset.
V
–10 to +10 V
0 V
Float
AIN Parameters (s: 387), AIN2.ZERO (s:
409)
No 16 bit Yes M_01-06-03-000
