AKD Benutzerhandbuch | 25.16.28 FB1.SELECT
FB1.SELECT Feedback Types
Type
0
10
11
20
21
30
31
32
33
34
40
41
42 Tamagawa
46 Hiperface DSL
Related Topics
8.2 Rückführung 1
630 KOLLMORGEN | Mai 2013
Description
Unknown
Incremental encoder with A/B Quad, marker pulse and Hall
Incremental encoder with A/B Quad, marker pulse and no Hall
Sine Encoder , with marker pulse and Hall
Sine encoder , with marker pulse & No Halls
EnDat 2.1 with Sine Cosine
EnDat 2.2
BiSS with Sine Cosine
HIPERFACE
BiSS Mode C Renishaw
Resolver
SFD
