AKD Benutzerhandbuch | 25.24.7 IL.FBSOURCE

25.24.7 IL.FBSOURCE

General Information
Type
Description
Units
Range
Default
Value
Data Type
Start Ver-
sion
Fieldbus Information
Fieldbus Index/Subindex Is 64 bit? Attributes Signed?
Modbus 1730
Description
This parameter selects the feedback source that current loop uses for commutation angle calculation.
0 = Primary feedback
1 = Secondary feedback
For induction motor closed loop control the commutation angle is set as shown in the following figure.
Related Topics
MOTOR.TYPE (s: 800)
R/W
Sets the feedback source for the current loop. Only applies when
MOTOR.TYPE = 4.
N/A
0 to 1
0
Integer
M_01-08-00-000
No 8-bit No
KOLLMORGEN | Mai 2013 718
