AKD Benutzerhandbuch | 25.16.3 FB1.ENCRES

25.16.3 FB1.ENCRES

General Information
Type
Description
Units
Range
Default
Value
Data Type
See Also
Start Version M_01-00-00-000
Variants Supported
AKD BASIC
AKD SynqNet
AKD EtherNet/IP
Fieldbus Information
Fieldbus
EtherCAT COE and CAN-
open
Fieldbus Index/Subindex Is 64 bit? Attributes Signed? Object Start Version
Modbus 282
Description
This parameter sets or gets the resolution of the motor encoder (encoder feedback systems only) in
number of counts per revolution for a rotary motor and the number of encoder pitches per motor pole pitch
for a linear motor. The number of encoder counts per revolution is obtained by multiplying the motor cat-
alog resolution in units of PPR by four. For example, for a 1024 PPR resolution motor, the number of
encoder counts per revolution is 1024*4 = 4096. For this motor FB1.ENCRES must be set to 4096.
For linear motors, the value of FB1.ENCRES is set to the number of encoder pitches per motor pole pitch.
For a motor with 32 mm pole pitch, and a 40 µm encoder pitch, the value for FB1.ENCRES should be set
to 32 mm/40 µm = 800.
Depending on the value of FB1.IDENTIFIED, FB1.ENCRES changes between read-only and read-write.
The following table lists the FB1.IDENTIFIED values and FB1.ENCRES's corresponding type.
10 (Incremental encoder)
11 (Incremental encoder, no halls) R/W
20 (Sine encoder)
21 (Sine encoder, no halls)
30 (Endat 2.1)
31 (Endat 2.2)
32 (biSS)
600 KOLLMORGEN | Mai 2013
Depends on FB1.IDENTIFIED. See table in description
below.
Sets the resolution of the motor encoder.
Encoder counts
32
0 to 2 -1
1,024
Integer
N/A
Variant
No
FB1.IDENTIFIED value
Supported
√
√
√
Index/Subindex Object Start Version
3533h/0 M_01-00-00-000
32 bit No
FB1.ENCRES type
R/W
R/W
R/W
R/O
R/O
R/O
M_01-03-00-000
