AKD Benutzerhandbuch | 25.24.36 IL.VVFB

25.24.36 IL.VVFB

General Information
Type
Description
Units
Range
Default
Value
Data Type
See Also
Start Version M_01-00-00-000
Variants Supported
AKD BASIC
AKD SynqNet
AKD EtherNet/IP
Fieldbus Information
Fieldbus Index/Subindex Is 64 bit? Attributes Signed? Object Start Version
Modbus 478
Description
The range for this parameter depends on whether the drive model is an MV/240 Vac or an HV/480 Vac.
The VBusScale parameter sets the drive model:
MV/240 Vac: VBusScale = 1
HV/480 Vac: VBusScale = 2
VBusScale is used for multiple parameter ranges that are model dependent, such as IL.KP.
Related Topics
Stromregelkreis (s: 138)
747 KOLLMORGEN | Mai 2013
R/O Parameter
Reads the measured voltage on the v-winding of the
motor.
V
–1200*VBusScale to +1200*VBusScale
N/A
Integer
IL.VUFB (s: 746)
Variant Supported
No 16 bit
√
√
√
Yes M_01-03-00-000
