AKD Benutzerhandbuch | 25.2.6 AIN.OFFSET

25.2.6 AIN.OFFSET

General Information
Type
Description
Units
Range
Default
Value
Data Type
See Also
Start Version M_01-00-00-000
Variants Supported
AKD BASIC
AKD SynqNet
AKD EtherNet/IP
Fieldbus Information
Fieldbus Index/Subindex Is 64 bit? Attributes Signed? Object Start Version
Modbus 6
Description
AIN.OFFSET sets the analog offset, which is added to the analog input command to the drive. This value
compensates for the analog input signal (AIN.VALUE (s: 398)) offset or drift.
Related Topics
Analogeingang (s: 117)
Blockschaltbild für den Positions-/Geschwindigkeitsregelkreis (s: 328) (for the drive controller envi-
ronment).
NV Parameter
Sets the analog input offset.
V
–10 to +10 V
0 V
Float
AIN Parameters (s: 387), AIN.ZERO (s:
401)
Variant Supported
No 16 bit
√
√
√
Yes M_01-03-00-000
KOLLMORGEN | Mai 2013 395
