AKD Benutzerhandbuch | 25.12.11 DOUT21.STATEU to DOUT32.STATEU

25.12.11 DOUT21.STATEU to DOUT32.STATEU

General Information
Type
Description
Units
Range
Default
Value
Data Type
See Also
Start Version M_01-01-01-000
Variants Supported
Supported by any AKD with extended IO.
Fieldbus Information
Fieldbus Index/Subindex
Modbus
Description
DOUTx.STATEU sets the state of the digital output node as follows:
0 = deactivated
1 = activated
DOUTx.STATEU is used when DOUT1.MODE to DOUT19.MODE (s: 501) = 0 (user mode).
Related Topics
Digitalausgänge (s: 107)
R/W Parameter
Sets the state of the digital output
node.
N/A
0 to 1
0
Integer
N/A
1472 DOUT21.STATEU
1482 DOUT22.STATEU
1492 DOUT23.STATEU
1502 DOUT24.STATEU
1512 DOUT25.STATEU
1522 DOUT26.STATEU
1532 DOUT27.STATEU
1542 DOUT28.STATEU
1552 DOUT29.STATEU
1562 DOUT30.STATEU
Is 64 bit? Attributes Signed?
No 8 bit No
KOLLMORGEN | Mai 2013 511
