AKD Benutzerhandbuch | 25.31.3 PLS.P1 TO PLS.P8

25.31.3 PLS.P1 TO PLS.P8

General Information
Type
Description
Units
Range
Default
Value
Data Type
See Also
Start Version M_01-02-03-000
Data Type
Variants Supported
AKD BASIC
AKD SynqNet
AKD EtherNet/IP
Fieldbus Information
EtherCAT COE and CANopen
Fieldbus Index/Subindex Is 64 bit? Attributes Signed? Object Start Version
Modbus
Description
PLS.P1 to PLS.P8 define the trigger point of the PLS. For further information about how these parameters
affect PLS behavior, see the PLS.UNITS parameter description.
Related Topics
863 KOLLMORGEN | Mai 2013
R/W Parameter
Sets the trigger point for programmable limit
switches.
Depends on UNIT.PROTARY or UNIT.PLINEAR
N/A
0
Float
UNIT.PROTARY (s: 938)
AKD BASIC Information
Integer
Variant
Fieldbus
622 PLS.P1
626 PLS.P2
630 PLS.P3
634 PLS.P4
Yes
638 PLS.P5
642 PLS.P6
646 PLS.P7
650 PLS.P8
Supported
√
√
√
Index/Subindex
34A0h/1 PLS.P1
34A0h/2 PLS.P2
34A0h/3 PLS.P3
34A0h/4 PLS.P4
34A0h/5 PLS.P5
34A0h/6 PLS.P6
34A0h/7 PLS.P7
34A0h/8 PLS.P8
64 bit Yes M_01-03-00-000
Object Start Version
M_01-02-03-000
