AKD Benutzerhandbuch | 25.39.5 UNIT.PLINEAR

25.39.5 UNIT.PLINEAR

General Information
Type
Description
Units
Range
Default
Value
Data Type
See Also
Start Version M_01-00-00-000
Variants Supported
AKD BASIC
AKD SynqNet
AKD EtherNet/IP
Fieldbus Information
Fieldbus Index/Subindex Is 64 bit? Attributes Signed? Object Start Version
Modbus 782
Description
UNIT.PLINEAR sets the units type for the position parameters when the motor type (MOTOR.TYPE) is
linear.
Type
0
1
2
3
4
Related Topics
Auswählen von Einheiten für Ihre Anwendung (s: 96)
936 KOLLMORGEN | Mai 2013
NV Parameter
Sets the linear position units.
N/A
0 to 4
0
Integer
PL.FB (s: 846), PL.CMD (s: 838), MOTOR.TYPE (s:
800)
Variant
No
Description
32-bit counts
Millimeters (mm)
Micrometers (µm)
(PIN/POUT) per rev-
olution
16-bit counts
Supported
√
√
√
8 bit No M_01-03-00-000
