AKD Benutzerhandbuch | 25.41.11 VL.FBFILTER

25.41.11 VL.FBFILTER

General Information
Type
Description
Units
Range
Default
Value
Data Type
See Also
Start Version M_01-00-00-000
Variants Supported
AKD BASIC
AKD SynqNet
AKD EtherNet/IP
Fieldbus Information
Fieldbus
EtherCAT COE and CAN-
open
Fieldbus Index/Subindex Is 64 bit?
Modbus 858
Description
This parameter returns the same value as VL.FB (s: 965), filtered through a 10 Hz filter.
Related Topics
13.4 Geschwindigkeitsregelkreis
R/O Parameter
Filters VL.FB (s: 965) value; active in opmodes 1 (velocity) and 2 (position)
only.
Depends on or
Rotary: rpm, rps, deg/s, (custom units)/s, rad/s
Linear: counts/s, mm/s, µm/s, (custom units)/s
N/A
N/A
Float
VL.FB (s: 965)
Variant Supported
Index/Subindex Object Start Version
3407h/1
Yes low 32 bit word Yes
√
√
√
M_01-00-00-000
Attributes Signed? Object Start Version
M_01-03-00-000
KOLLMORGEN | Mai 2013 966
